6800K Beam Led Moving Head LED Profile Spot Light 7 Colors 980W

Ask Lasest Price
Brand Name :	Bright lighting
Model Number :	BR-700F
Certification :	CE ISO9000
Price :	Negotiable
Payment Terms :	T/T, Western Union, MoneyGram
Supply Ability :	3000PCS per month
Delivery Time :	7-15days

Add to Cart

Product Details
Company Profile

6800K Beam Led Moving Head LED Profile Spot Light 7 Colors 980W

700W LED Module BSWF Led Moving Head Profile Stage Light Wash Zoom Light

Specifications:

Input voltage:	AC100-240V, 50/60Hz
Rated power	980W
Light source:	700W LED module
LED life:	20,000 hours
Color temperature:	6800K
Caliber:	138mm Frontal lens for greater performance
Color rendering index	Standard mode Ra>75, high CRI mode Ra>90
Luminous flux:	28000LM
Signal interface:	three-pin XLR (five-pin XLR optional)
Control mode:	DMX512, RDM, Auto Mode, master-slave, Sound activation
Channel mode:	36CHs
Display system:	2.7-inch touch LCD display, Chinese and English display, 180-degree rotation
Fixed color:	7 colors + open position
Color mixing system:	independent CMY color mixing system
Color temperature adjustment:	independent CTO 2700K-7000K linear adjustment
Prisms:	Rotating 3-faced prism+6-faced linear prism, two prisms can be overlaid
Effect wheel:	dynamic effects such as stunning simulated dynamic flames, gurgling water, etc.
Fixed Gobo wheel:	8 fixed gobos+open position
Rotating gobo Wheel:	6 gobos (pluggable), outer diameter 27.9mm, effective diameter 16.5mm, thickness 1.1mm+Open position
Framing system:	4 Individually positionable Shutter Blades, each piece can be closed separately and can be rotated +/- 90°
Frost system:	0~100% linear atomization
Iris system:	5%~100% smooth adjustment
Beam Aperture:	4.5°~50° fast motorized linear zoom
Dimming system:	0-100% linear adjustment
Strobe system:	the highest frequency can reach 25Hz, and random strobe and pulse strobe can be selected
Pan	540° (16 bit precision scanning)
Tilt:	270° (16 bit precision scanning)
Pan/Tilt:	Five-phase motor with magnetic encoding positioning function
Protection rate:	IP20
Working environment:	0-45
Product size:	510345800(mm)
Carton size:	730690590 (mm)
Product net weight:	40KG
Product gross weight:	48.5KG
Product appearance:	flame retardant, high temperature resistance, folding clamp

Additional details:

Working principle
1:LED light: When current passes through the LED chip, the LED chip emits visible light. The combination of LED chips of different colors can present rich lighting colors.
2:Moving system: Using a Moving Head design, including a rotating structure on both horizontal and vertical axes, it can achieve fast and precise light positioning and movement.
3:Lighting effects: Combining the three lighting effects of Beam, Spot, and Wash, different beam shapes and motion trajectories can be achieved through built-in programs or external controllers.
4:Framing system: equipped with a special pattern imaging device, which can achieve precise pattern imaging and special-shaped projection, increasing the visual impact.
5:Dimming and color control: Through PWM dimming technology and RGB mixing technology, precise control of LED brightness and color can be achieved

Application:

1:Fashion show: suitable for fashion shows, fashion conferences and other activities, using lighting effects to enhance the display effect of clothing and models.

2:Theme parks: Provide scenery lighting and special effects presentations for theme parks, amusement parks, etc. to enhance tourists’ viewing experience.

Service:

Provide after-sales service

display:
